  Secure Wall Amplifier
240W rms with UHF Radio Microphone


  We are no longer able to supply this item. Please see Home Page for details


adastra

Order Code
953.150UK

EAN Barcode
5015972224984

Model Number
SA240
Adastra SA240 Secure Wall Amplifier with UHF Mic + Media Player - 953.150UK





2 switchable mic/line inputs --- Switchable phantom power for condenser mics --- UHF wireless handheld mic included --- USB/SD media player --- Bluetooth receiver --- 100V or low impedance operation --- Secure lockable cabinet

Public address mixer-amplifier built into a surface-mount secure box. A total output of 240W can drive either 100V line or low impedance speakers from binding post terminals inside the cabinet. The system includes a handheld UHF microphone with an inbuilt receiver and 2 switchable wired mic/line inputs are provided on combo XLR/jack sockets. Each mic input has switchable +48V phantom power and priority override, whch mutes the Aux inputs during voice operation. An internal media player enables playback of audio tracks from USB/SD player, FM tuner or Bluetooth pairing. Alternatively, line inputs can be connected to the Aux 1 RCA sockets or separate Aux 2 RCA/3.5mm jack sockets. The combination of flexible input section and a high efficiency amplifier in a strong, lockable cabinet provides a complete solution for buildings where security and ease of use is essential.



Power supply170-264Vac, 50Hz (IEC)
FuseF2AL (20x5mm)
Carrier frequency864.5MHz
Batteries : handheld transmitter2 x AA (alkaline)
Wireless range50m (max)
Output power : rms240W
Speaker outputs8 Ohm / Com / Com / 100V
Music sourceUSB/SD player, FM tuner, Bluetooth
Mic/line inputs2 x combo XLR/jack
Line inputsRCA (Aux 1), RCA or 3.5mm jack (Aux 2)
Line outputXLR male connector
EqualizationBass + Treble each channel
Dimensions375 x 345 x 160mm
Weight7.191kg
Amplifier : constructionClass-D + output transformer
Phantom power+20V switchable to each XLR input
THD<0.4% @ 1kHz
Input impedanceMic: 600 Ohms / Line: 10k Ohms
Input sensitivityMic: -42dB / Line: -10dB
SNRMic: 66dB / Line: 76dB
Bluetooth version2.0
Frequency response : lineLine 1+2: 80Hz-24kHz, Line 3+4: 85Hz-24kHz
Frequency response : mic85Hz-22kHz
