  HDMI V2.0 4K Splitter 1x2

  We are no longer able to supply this item. Please see Home Page for details


avlink

Order Code
128.845UK

EAN Barcode
5015972223918

Model Number
HDS12v2.0
AV:Link HDS12v2.0 4K HDMI 2.0 Splitter - 128.845UK





Simple connection and installation --- Supports HDMI v2.0 resolutions up to 3840 x 2160 @ 60Hz for compatibility with the latest 4K digital TV boxes --- Gold plated HDMI connectors for optimum signal transfer --- Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats --- Ideal for entertainment, hospitality and other commercial venues requiring multiple display feeds from a single HDMI source --- UK power adaptor supplied --- Sleek design with tough metal chassis

Slimline 4K HDMI splitters to easily connect a single HDMI source to multiple displays at the same time. This updated version will support HDMI v2.0 which is compatible with the latest 4K digital TV boxes producing 3840 x 2160 @ 60Hz resolution.



Max. baud rate18Gbps
Output connections2x HDMI
Dimensions128 x 53 x 23.5mm
Weight139g
Max. working current450mA
Power supplyInput: AC (50Hz, 60Hz) 100-240V, Output: DC5V/1A
HDMI versionv2.0b
Video resolutionUp to 3840 x 2160 @ 60Hz
Display colours8/10/12bit deep colour
Audio formatDTS-HD, Dolby True, DTS, Dolby-AC3 and DSD
HDCP version2.2
Max. bandwidth600MHz
Transmission distance35m max 4K @ 30Hz and FHD or 10m max 4K @ 60Hz
Operating temperature range-15°C to +55°C
